Component | Chemical Name | Molecular formula | Weight | ||
R143a | 1,1,1-Trifluoroethane | CH3CF3 | 52% | ||
HFC-134a | 1,1,1,2-Tetrafluoroethane | CH2F2 | 4% | ||
HFC-125 | Pentafluoroethane | CH2FCF3 | 44% | ||
Molecular Weight | 97.6 | ||||
Boiling Point(760mmHG) /°C | -46.2 | ||||
Critical Temperature / °C | 72.2 | ||||
Critical Pressure /kPa | 3668.6 | ||||
Odor | Slight ethereal | ||||
Form | Liquefied Gas | ||||
Color | Clear,odorless | ||||
Heat of Vaporization at Boiling Point, KJ/KG | 35.8 | ||||
Vapor Pressure (25°C) /Kpa | 1255 | ||||
Vapor Densitey at (25°C) (Air = 1) | 5.26 | ||||
Density of Saturated Liquid (25°C, g/cm3) | 1.034 | ||||
Ozonosphere Damage Potency (ODP) | - | ||||
Global Warming Potency (GWP100) | 3800 | ||||
Ashare | A1/A1 | ||||
Flammability at 1 atm. And 18 °C | Non - Flammable | ||||
Purity /% ≥ | 99.8 | ||||
Moisture /% ≤ | 0.001 | ||||
Acidity (calculated with HCL) /% ≤ | 0.00001 | ||||
High Boiling Residue /%≥ | 0.01 | ||||
Volume of Non-Condensable-Gases at (25℃) /% ≤ | 1.5 |
